Inspired Performance
Inspired Performance
₹52,000.00
| Technical Specification | Values |
| Capacity | 408 Kg. |
| Speed Range (m/s) | 0.66 |
| Gear Ratio | 40:1 |
| Power Range | 4 Kw |
| Current (A) | 9 |
| Brake Voltage | DC 110 V / 1A |
| Main sheave Diameter | 520 mm |
| No. Of Groove | 13 mm , 3 Rope, 20 Pitch |
| Pole | 4 |
| Motor Speed | 950 rpm |
| Voltage | 380 |
| Frequency (Hz) | 33 |
| Oil Capacity | 4.0 Ltr. |
| Weight of Machine- Without Base Plate | 200 Kg. |
Max Travel- G+6
GEARED ELEVATOR TRACTION MACHINE- PREMIUM QUALITY-9904044388
Versatile and compact machine.
Certified Quality Assurance.
Smooth and comfort ride.
Maximum Output Torque.
Energy Efficient VVVF Motor.
Brake Noise Below 30 db.
Horizontal Vibration Below 0.7 mm/sec.
